A Kansas land surveyor seal is a two-ring circle, 1 5/8 inches across the outer ring and 1 1/16 inches across the inner, carrying your name, certificate number, LICENSED, KANSAS and PROFESSIONAL SURVEYOR. You sign and date across the impression. A rubber stamp, embossed seal or digital seal all qualify. This page covers wording, size, devices, signing, digital rules and ordering.
Engineer Seal Stamps compliance desk. Checked against Kan. Admin. Regs. 66-6-1(a) and the State Board of Technical Professions. Sources read September 2026.
| Requirement | What the rule says | Source |
|---|---|---|
| Layout | A circle inside a circle, sharing one center | Kan. Admin. Regs. 66-6-1(a) |
| Dimensions | Outer ring 1 5/8 inches across; inner ring 1 1/16 inches across | Kan. Admin. Regs. 66-6-1(a) |
| Name | Matches the name printed on your license | Kan. Admin. Regs. 66-6-1(a) |
| Number | Your license certificate number | Kan. Admin. Regs. 66-6-1(a) |
| Fixed words | LICENSED and KANSAS, with PROFESSIONAL SURVEYOR set in the lower ring | Kan. Admin. Regs. 66-6-1(a) |
| Devices | Rubber stamp, embossed seal or digital seal | Kan. Admin. Regs. 66-6-1(a) |
| Signature and date | Written by hand or applied as an authenticated digital signature, running across the impression | Kan. Admin. Regs. 66-6-1(b)(1) |
| Documents | Each document, with original land descriptions that convey an interest in real property named outright | Kan. Admin. Regs. 66-6-1(c), (d), (e) |
| Digital signature | Unique to you, verifiable, in your sole control and tied to the file so any change voids it | Kan. Admin. Regs. 66-6-1(b)(3), (4) |
| Expired or revoked license | Stamping is unlawful | Kan. Stat. Ann. § 74-7023(d) |
Kansas is one row in our land surveyor seal requirements by state table, which sets each jurisdiction's rule side by side. Not yet licensed? The land surveyor licensing path by state lays out the steps Kansas requires first.
What wording does a Kansas land surveyor seal carry?
Six things, all set by Kan. Admin. Regs. 66-6-1(a): two concentric circles, your name as your license shows it, your license certificate number, the words LICENSED and KANSAS, and PROFESSIONAL SURVEYOR in the lower ring.
Read the legend closely. It is two words, PROFESSIONAL SURVEYOR, and LAND is not one of them, so a die with a longer legend does not match the regulation. Beyond the lower ring for the legend, this page does not give positions for the other items. Our overview of Kansas land surveyor seal regulations gives background on the credential.
How large is the Kansas seal?
The regulation gives exact figures. The outer circle measures 1 5/8 inches in diameter and the inner circle 1 1/16 inches. The seal is circular, and the text states a single size for each ring rather than a range.
Those two numbers are your order specification. A die cut to any other diameter, even one that looks close on paper, does not match the stated figures. See our post on designing a Kansas land surveyor seal for how the two rings divide the face.
Why do Kansas surveyors sign across the seal instead of beside it?
Because Kan. Admin. Regs. 66-6-1(b)(1) requires you to sign and date across the seal. The signature may be handwritten or an authenticated digital signature, and either way it crosses the impression instead of sitting next to it.
This shapes your title block. Keep the seal clear of other text and border lines so a signature and date written over it stay readable, and make sure the ink you sign with shows up against the printed rings.
Can you use a rubber stamp, an embosser or a digital seal in Kansas?
All three. Kan. Admin. Regs. 66-6-1(a) lists a rubber stamp, an embossed seal and a digital seal as acceptable forms. The design and dimension rules above apply to whichever form you choose.
An inked stamp suits paper plats, and a digital version of the same face suits PDFs, and nothing stops you from holding both. Our post on the Kansas land surveyor stamp compares the physical options.
Which Kansas documents require the seal?
Each document you issue. Under Kan. Admin. Regs. 66-6-1(c), (d), (e), that includes drawings, technical reports, records, papers and original land descriptions written for conveying an interest in real property. The last category reaches descriptions some surveyors handle as ordinary correspondence.
A legal description written for a conveyance is therefore sealed work, whatever form it travels in. Treat it the same way you treat a plat: seal, signature and date, with the signature and date across the impression.
What does Kansas require of a digital signature?
Under Kan. Admin. Regs. 66-6-1(b)(3), (4), a digital signature must be unique to you, verifiable, kept under your sole control and tied to the document in a way that makes any alteration invalidate it.
Those conditions describe how the signing works. A digital seal image on a PDF still needs a signature across it, and when that signature is digital it has to meet all four conditions. Our post on points to weigh before buying a Kansas land surveyor seal covers the digital option alongside the physical ones.
What happens if a Kansas license expires or is revoked?
Stamping becomes unlawful. Kan. Stat. Ann. § 74-7023(d) prohibits sealing with a license that has expired or been revoked, so the device has to stay out of use while your license is in either state.
Put your renewal date on the calendar well ahead of time. A lapse stops sealing on every open job at once, not just on the next plat.
What should you send when ordering a Kansas seal?
Your name exactly as it appears on your license and your license certificate number. The remaining text, LICENSED, KANSAS and PROFESSIONAL SURVEYOR, and the two ring sizes come from the regulation, so none of them is a choice.
Decide which forms you need: rubber stamp, embossed seal, digital seal, or more than one. Our post on why the Kansas professional land surveyor seal matters explains the seal's role on your work.
How do you check a Kansas impression before using it?
Measure it. The outer ring should read 1 5/8 inches and the inner ring 1 1/16 inches. Then confirm that PROFESSIONAL SURVEYOR sits in the lower ring and that your name and certificate number match your license.
Next, sign and date across a test impression to make sure the signature stays legible over the printed text. Finally, check that LICENSED and KANSAS both appear in full.
If you also hold a Kansas geologist license, the Kansas geologist seal rules set out what that seal must carry.
Frequently asked questions
Can the lower ring read PROFESSIONAL LAND SURVEYOR?
The regulation's wording for the lower ring is PROFESSIONAL SURVEYOR. Adding LAND produces a legend the regulation does not list, so order the two-word form.
Is an embossed seal on its own acceptable?
Yes. Kan. Admin. Regs. 66-6-1(a) names the embossed seal as one of three accepted forms, alongside the rubber stamp and the digital seal.
Does the date also go across the seal?
Yes. The signing rule sends the date over the impression too, not just your signature.
Is there any size tolerance on the rings?
The regulation states one figure per ring, 1 5/8 inches and 1 1/16 inches, and gives no range. Order to those numbers.
Which board oversees Kansas surveyor seals?
The State Board of Technical Professions. The seal design on this page comes from Kan. Admin. Regs. 66-6-1(a), and the lapse rule from Kan. Stat. Ann. § 74-7023(d).
